Updated R5 edge banding machine

Aluminium Beam,Tilting fine trimming unit and big wheel for trimming and scraping units

Working more steady and more easier adjustment

Functions:Edging-End trimming-Fine trimming-Scraping-Buffing

Detla PLC and Touch screen,China brand motors

Thickness of Working board:10-60mm

Thickness of PVC belt:0.4-3mm

Feeding speed:10-20m/min

Min.Width of Working board:60mm

Min.Length of Working board:150mm

Air compressure:0.6-0.8Mpa

Outline size of machine body:3600x800x1800mm

Net weight:About 800kgs
